63
Nylon Nut M6*H6*S10
4
94
Wave Washer
1
64
Magnet
1
95
Tension spring
1
65
Belt Plate
1
96
Bolt M8*12*Φ10*5.5*S5
1
66
Belt
1
97
Washer d12*Φ17*0.5
1
67L/R
Cover L/R
2
98
Idler rod
1
68
Bolt ST4*10*Φ6
8
99
Washer d6*Φ12*1.2
2
69L/R
Chain Cover
2
100
Washer d12
2
70
Bolt ST4.2*16*Φ8
6
101
Magnetic board Join
1
71
Washer d6*Φ16*1.5
9
102
Tension spring
1
72
Bolt ST4*13*Φ8
4
103
Magnet
8
73
Small cover on crank cover
2
104
Magnetic plate shaft
1
74
Crank
2
105
Aluminum sheet
2
75
Crank cover
2
106
Sliding tube 1
1
76
Close cover on crank cover
2
107
Power Trunk Wire
1
77
Hexagon Bolt M10*50
2
108
Motor
1
78
Sensors
1
109
Electric tension line
1
79
Sensors holder
1
110
Spacer Φ14*55*M8
2
80
Trunk Wire 2
1
111
Rail
1
81
Hexagon Nut M10
2
112
Washer d8*Φ16*1.5
4
82
Bolt M6*40
2
113
Bushing 3
4
83
Chain U seat
2
114
Sliding tube 2
1
84
Hexagon Nut M6*H5*S10
2
115
End cap F38*38
1
85
Hexagon Thin Nut M10*1
1
116
End cap F30*30*16
1
86
Spacer Φ15*Φ10.2*9
1
117
Knob
1
87
Wave washer d
1
118
Bushing
4
88
Flywheel
1
119
Nut M10*8*S16
2
89
Flywheel shaft
1
120
Hook
2
90
Cone hexagon thin nut
M10*1
1
121
Bushing
1
91
Hexagon Bolt M6*10*S10
5
A
Spanner S13-14-15
1
92
Bearing 6001-2RS
2
B
Wrench S5
1
93
Idler Pulley
1
