Je bekijkt pagina 25 van 40
25
No. Description Drawing No. Qty
1 Shoulder Screw M5xΦ6x25 16052510 1
2 Pointer 1906-00022-1 1
3 Spacer 1906-00001-4 11
4 Washer M6 11060010 3
5 Lock Nut M5 13050011 1
6 Front Cap, Rod 1906-00021-1 1
7 Allen Screw M5x12 16051221 3
8 Washer M8 11080000 3
9 Spring (Long) 1906-00016-4 1
10 Rare Cap, Rod 1906-00039-1 1
11 Spring (Short) 1906-00035-4 1
12 Blade Cover 1906-00041-2 1
13 Rare Rod 1906-00043-1 1
14 Spring Pin Φ3x14 19031401 1
15 D Pin 1906-00014-4 1
16 Inner Shield 1906-00030-2 1
17 Spacer 1906-00015-4 6
18 Washer M5 11050010 2
19 Spring Washer M5 12050010 2
20 Allen Screw M5x16 16051620 2
21 Spring Washer M8 12080000 2
22 Bolt M8x25 15080250 2
23 Bolt M5xΦ6x10 16051010 5
24 Inner Plastic Shield 1906-00046-4 1
25 Washer M5 11050000 5
26 Lock Nut M5 13050001 5
27 Rare Shield 1906-00045-2 1
28 Allen Screw M5x30 16053021 2
29 Skid 1906-03000-4 1
30 Front Shield 1906-00018-2 1
31 Spacer, Front Shield 1906-00013-2 1
32 Front Rod 1906-00031-1 1
33 Pin Φ6.35x32 1906.353202 1
34 Guide Wheel 1906-00047-4 1
35 Oil Sealing Φ19xΦ12x3 1906-00048-4 2
36 Bushing 1906-00024-1 2
37 Allen Screw M5x30 16053020 5
38 Lock Nut M6 13060001 2
39 Washer M6 11060000 4
40 Circlip Φ8 18080003 2
BLADE COVER ASSEMBLY
