10. TROUBLESHOOTING
Please check the list below before addressing the problems to servicing personnel
including local dealer. And if the problem continues aer the troubleshooting as described
below, call your local dealer for future assistance.
Check to see if the diamond blade is worn out, glazed, warped or damaged.
Ensure skid plate moves freely up and down the entire sha length without contacting the diamond
blade.
Check skid plate for excessive wear or gap around the diamond blade.
Check bottom of skid plate for metal burrs or irregularities.
Ensure skid plate is not twisted or bent.
Check lexan covers for free movement up and down.
Ensure there is spring down pressure at each end of the skid plate.
Do not twist or move the saw sideways while cutting. Make gradual changes in pressure on the
handlebar to control the saw in the cut.
Check that the engine is running properly and at full throttle.
Check belt and belt idler for proper tension.
Ensure the diamond blade is properly mounted and secured with clean flanges.
Ensure that the diamond blade is the correct specification for your area.
Ensure the slab is in clean with no debris that could raise the skid plate or saw while cutting.
Use Tomahawk Power joint protectors at all cut intersections.
Clean excess concrete debris from the blade block assembly.
Check that the scrapers in the blade block are not bent or binding.
Ensure that the blade block shas are not bent or damaged.
Check that the front guide is properly aligned with the center of the diamond blade.
Check to see if the diamond blade is worn out, glazed, warped or damaged.
Do not twist or move the saw sideways while cutting. Make gradual changes in pressure on the
handlebar to control the saw in the cut
Ensure that all wheels rolls freely and smoothly.
Do not force the saw. Allow the diamond blade to cut at its own rate of speed.
Check the skid plate for damage or burrs.
Check if there is fuel in the tank and it is the correct fuel. Make sure there is no water in the fuel.
Check if the fuel valve is turned to the 'on” position.
Check if the ON/OFF switch is in the 'ON” position.
Check that the spark plug wire is connected to the spark plug.
Engine is flooded. Adjust the choke per the engine owner’s manual.
Check the choke is in the 'ON” position for cold starts. Adjust the choke per the engine owner’s manual.
Oil level is too low. Engine is equipped with an oil alert system that will not let the engine start unless
the engine oil level is within the correct range.
Check that air cleaner is not dirty or plugged.
Check that the blade sha rotates freely and no concrete has built up in the blade block.
Check if there is fuel in the tank and it is the correct fuel. Make sure there is no water in the fuel.
Oil level is too low. Engine is equipped with an oil alert system that will not let the engine start unless
the engine oil level is within the correct range.
Check that air cleaner is not dirty or plugged.
Check that spark plug is clean and properly gapped.
Check that throttle lever is properly set.
Check the choke is in the 'ON” position for cold starts. Adjust the choke per the engine owner’s manual.
Saw is spalling
and ravelling
cut
Saw pulls to
one side
while sawing
Engine does
not start
Engine runs
rough, back
fires or can not
reach full
speed.
