16
• Open the engine throttle lever to full open position for maximum engine speed.
• Line up the saw with the cut line using the white wheel on the front guide and the
triangle pointer on the back of the blade block.
• To lower the blade into the concrete slowly, push down on the saw handle and pull the
blade release lever.
• Push the saw forward to cut, keeping the front guide wheel in the cut line.
• Push the saw at about half speed for the first 50 feet to allow the blade to develop good
diamond exposure.
• Increase the forward speed of the saw until the blade and engine are working at
maximum efficiency. DO NOT force the saw.
• When approaching a wall, raise the front guide and use the triangle guide at the back of
the blade block to cut the last few feet.
• DO NOT hit the blade block assembly against any
object. Damage may result.
The Tomahawk Early Entry Concrete Saws’ default blade
setting is adjusted to the max blade depth of 1-3/16”
(ASTM Standard Specification for Portland Cement). If a
shallower cut is desired, follow these steps:
• Loosen the depth adjustment nut (1) above the front
right wheel, counter-clockwise with a 13mm wrench.
• Turn the depth stop adjustment bolt (2) clockwise with
a Size 5 Metric Allen wrench. Each full revolution of the
bolt will reduce the cut depth by 1/8".
• Make sure the rear wheels are flat on the ground by
pushing down on the rear of main frame.
• Follow an existing saw joint cut for approximately one
foot to confirm that the proper/desired cut is achieved.
21
