5. SPECIFICATIONS
Model number TZ-200BS TZ-400BS
Information of EN / BS
Standard
Certified to the European Standard EN 54-24:2008
Loudspeaker for voice alarm systems for fire detection and fire alarm systems
DoP Number: 22-001
In compliance with the British Standard BS 5839-8:2008
Rated Input 20W 40W
Rated Impedance
100V line :
70V line :
500Ω (20W), 1kΩ (10W), 2kΩ (5W)
500Ω (10W), 1kΩ (5W), 2kΩ (2.5W)
100V line :
70V line :
250Ω (40W), 500Ω (20W), 1kΩ (10W)
250Ω (20W), 500Ω (10W),1kΩ (5W)
Frequency Response 130 Hz ~ 20 kHz (Peak-20dB) 110 Hz ~ 20kHz (Peak-20dB)
Sensitivity
92dB (1W, 1m, 100 ~ 10kHz, pink noise)
80dB (1W, 4m, 100 ~ 10kHz, pink noise)
93dB (1W, 1m, 100 ~ 10kHz, pink noise)
81dB (1W, 4m, 100 ~ 10kHz, pink noise)
Maximum
Sound Pressure level
105dB (20W, 1m, 100 ~ 10kHz, pink noise)
93dB (20W, 4m, 100 ~ 10kHz, pink noise)
109dB (40W, 1m, 100 ~ 10kHz, pink noise)
97dB (40W, 4m, 100 ~ 10kHz, pink noise)
Coverage Angle (-6dB)
500Hz: Horizontal 360°, Vertical 100°
1kHz: Horizontal 185°, Vertical 45°
2kHz: Horizontal 130°, Vertical 25°
4kHz: Horizontal 100°, Vertical 20°
500Hz: Horizontal 360°, Vertical 100°
1kHz: Horizontal 185°, Vertical 45°
2kHz: Horizontal 130°, Vertical 25°
4kHz: Horizontal 100°, Vertical 20°
Operating
Temperature
-30°C ~ +60°C
Dust/Water Protection IP 66
Environmental Type Type B (outdoor application)
Speaker Component Woofer: 8.9cm x 4, Tweeter: 8.2cm x 1 Woofer : 8.9cm x 8, Tweeter : 8.2cm x 1
Applicable Cable
0.6 - 0.3 mm
2
(AWG 22) for solid wire,
1.0 - 0.8 mm
2
(AWG 18) for 2-core wire
Cable Connection Screw terminal (steatite), 4 ports
Material Enclosure: Aluminum alloy, Grille: Aluminum
Finish White (RAL9016 or equivalent), paint
Dimension 610 (h) x 124 (w) x 108 (d) mm 1016 (h) X 124 (w) X 108 (d) mm
Weight 3.9 kg 6.7 kg
Accessory
Aluminum Alloy Multi Bracket (A) & (B)…1, Hexagonal screw…2, Washer…2
Self-tapping screw…4, Plastic wall plug…4
Traceability Information for Europe
Manufacturer:
TOA Corporation
7-2-1, Minatojima-Nakamachi, Chuo-ku,
Kobe, Hyogo, Japan
Authorized representative:
TOA Electronics Europe GmbH
Suederstrasse 282, 20537 Hamburg, Germany
URL : www.toa.eu
Traceability Information for UK
Manufacturer:
TOA Corporation
7-2-1, Minatojima-Nakamachi, Chuo-ku,
Kobe, Hyogo, Japan
Authorized representative:
TOA CORPORATIN (UK) LIMITED
Unit 7&8, The Axis Centre, Cleeve Road,
Leatherhead, Surrey, KT22 7RD, United Kingdom
URL : www.toa.uk
1488
202204
EN54-24:2008
22
DoP No.:22-001
