6
2. GENERAL DESCRIPTION
The TOA TS-D1000 Series is a conference system specially designed for easy set up, disassembly and storage.
It can be used by merely connecting a number of conference units* to the TS-D1000-MU Master control unit.
Up to 32 Conference units can be connected. This number can be increased to up to 246 units (up to
2 Chairman Units) by further connecting a maximum of 5 TS-D1000-SU Sub control units.
* Collective name of the two models: TS-D1000-CU Chairman unit and TS-D1000-DU Delegate unit
3. FEATURES
• By simply connecting the required number of Conference units to the Master control unit, the system’s fully
digital audio processing system can clearly amplify all conference participant voices.
• Up to 32 Conference units can be connected to each Master control unit (1 line: 16 units × 2 lines).
• Up to 246 Conference units can be connected in a system if the maximum of 5 Sub control units are also
used.
• Inter-equipment connections can be performed in a daisy chain conguration using Cat5e STP LAN cable.
• Either ’Standard’ or ’Long’ versions of the exible microphone arm can be selected for use with the Conference
unit.
• The Conference unit’s microphone arm is designed to be easily detachable for space-saving storage.
• A test function allows easy conrmation of the Conference unit’s connection status.
• Conference mode can be selected for more effective operation during conference proceedings.
• The number of Delegate units that can simultaneously speak can be limited using the Max. open mic No.
restriction function.
• The Mic auto-off function automatically turns off the microphone after approximately 30 seconds, even if the
user forgets to turn off the microphone after speaking.
• Since the Master control unit is provided with its own individual recording function, the contents of the
conference can be recorded to either internal memory or a commercially-available USB memory device.
External recording devices can also be connected.
• The Master control unit’s power save function automatically powers down the system if the user forgets to turn
the power off.
• Conference units can be set to mute the monitor speaker or reduce sound volume when the microphone is
switched ON to eliminate concerns about feedback (howling).* Even if feedback briey occurs, the Master
Control unit’s feedback suppressor (FBS) function provides highly effective control.
* Squeal or howling sounds caused by a feedback loop created when the microphone picks up sound output
from the speaker, which is then further amplied by an amplier.
4. AVAILABLE INSTRUCTION MANUALS
The following two instruction manuals are made available for the TS-D1000 Series digital conference system:
Manual Name Manual Outline Remarks
(1) Instruction manual General explanations of installation,connection,
operation, settings, etc
The manual currently in hand
(2) Instruction manual
(Browser settings)
Explanation of browser settings Web only
Note
Regarding (2) above, since some items can only be set using a web browser, download the manual from the
TOA DATA Library. (https://www.toa-products.com/international/).
