23
7.5.2. Accessing and deleting sound source files from the internal memory
A PC connected to the TS-D1000-MU via network is required to access or delete sound source les recorded
to the TS-D1000-MU’s internal memory.
A PC having the following specications is recommended:
Compatible PC Windows PC
Recommended operating system Windows 10 (64-bit)
Note
Windows is the registered trademark of Microsoft Corporation in the United States and other countries.
For more information regarding network connections and how to access or delete sound source les, please
refer to the separate Instruction Manual (Browser Settings), which can be downloaded from the TOA DATA
Library (https://www.toa-products.com/international/).
8. SYSTEM EXAMPLES
• In a basic system, a maximum of 32 Conference units can be connected to the Master control unit. (See the
"Basic System Example" below.)
• To connect more Conference units (33 to 246), add as many Sub control units as required to support the total
number of Conference units. (See "Expanded System Example – Connected Unit Expansion" on the next
page.)
• To extend the maximum distance of Conference unit connectivity, add the Extension unit. (See "Expanded
System Example – Distance Extension" on p. 25.)
Use a CAT5e STP cable tted with RJ45 connectors at both ends for connection.
8.1. Basic System Example
The Master control unit is equipped with 2 Conference unit connection terminals, each of which allows up to 16
Conference units to be connected in a daisy chain. The maximum distance from the Master control unit to the
last Conference unit in the daisy chain is 50 m (164.04 ft).
Up to 2 lines
Master control unit
Conference unit
connection terminal
Max. 50 m or 164.04 ft (Max. 16 Conference units)
Max. 50 m or 164.04 ft (Max. 16 Conference units)
