5. SPECIFICATIONS
ModelNo. PE-304BU PE-304WU PE-604BU PE-604WU
Enclosure Bass-reextype
RatedInput 30W(100Vline,70Vline,8Ω),3.7W(25Vline) 60W(100Vline,70Vline,8Ω),7.5W(25Vline)
Rated
Impedance
100Vline 330Ω(30W),1kΩ(10W),3.3kΩ(3W),
10kΩ(1.3W)
170Ω(60W),330Ω(30W),670Ω(15W),3.3kΩ(3W)
70Vline 170Ω(30W),330Ω(15W),1kΩ(5W),3.3kΩ(1.5W),
10kΩ(0.6W)
83Ω(60W),170Ω(30W),330Ω(15W),
670Ω(7.5W),3.3kΩ(1.5W)
25Vline 170Ω(3.7W),330Ω(1.9W),1kΩ(0.6W),
3.3kΩ(0.2W),10kΩ(0.1W)
83Ω(7.5W),170Ω(3.7W),330Ω(1.9W),
670Ω(0.9W),3.3kΩ(0.2W)
Low 8Ω
Sensitivity 90dB(1W,1m)(330Hz–3.3kHz,pinknoise)
FrequencyResponse 95Hz–20kHz(–10dB) 110Hz–20kHz(–10dB)
OperatingTemperature
–10°Cto+50℃(14℉to122℉)
SpeakerComponent 12cm(5")cone-type+balanceddome-tweeter(coaxial)
ULCode UL1480UUMW,ULC-S541
SpeakerCable 4-coreFPLlistedcable4.6m(15.09ft)
Finish Enclosure:
ABSresin,black
Grille:
Surface-treatedsteel
platemesh,black,paint
Enclosure:
ABSresin,white
(RAL9010equivalent)
Grille:
Surface-treatedsteel
platemesh,white
(RAL9010equivalent),
paint
Enclosure:
ABSresin,black
Grille:
Surface-treatedsteel
platemesh,black,paint
Enclosure:
ABSresin,white
(RAL9010equivalent)
Grille:
Surface-treatedsteel
platemesh,white
(RAL9010equivalent),
paint
Dimensions ø186x275(h)mm(ø7.32"x10.83")(unitonly)
Weight 2kg(4.41lb)(unitonly) 2.9kg(6.39lb)(unitonly)
[Sound pressure level at 10 ft]
ModelNo. PE-304BU,PE-304WU PE-604BU,PE-604WU
Impedance 170Ω 330Ω 1kΩ 3.3kΩ 10kΩ 83Ω 170Ω 330Ω 670Ω 3.3kΩ
100Vrms Wattagetap(W)
–
30 10 3 1.3
–
60 30 15 3
SPLperULReverberantRoom(dBA)
–
92 88.7 83.1 78.6
–
93.1 91.1 89 82.3
SPLperULCAnechoicRoom(dBA)
–
96.4 90.2 85.4 81.9
–
95.1 93.5 90.9 83.8
70Vrms Wattagetap(W) 30 15 5 1.5 0.6 60 30 15 7. 5 1.5
SPLperULReverberantRoom(dBA) 91.6 90.1 85.6 80.8 75.3 93.2 90.6 89.2 85.7 80
SPLperULCAnechoicRoom(dBA) 84.7 92.2 87.6 82.8 79.1 95 93.2 90.9 88.1 80.9
25Vrms Wattagetap(W) 3.7 1.9 0.6 0.2 0.1 7.5 3.7 1.9 0.9 0.2
SPLperULReverberantRoom(dBA) 83.4 80.7 76.3 71.8 66.1 84.7 83 80.5 7 7.1 71.1
SPLperULCAnechoicRoom(dBA) 86.5 83.8 78.9 74.1 70.4 87. 2 85.1 82.4 79.4 72.1
8Ω SPLperULReverberantRoom(dBA) 91.7 94
SPLperULCAnechoicRoom(dBA) 95.5 95.8
[Directional Characteristics]
Angle dBA
0°(onaxis) 0(reference)
±29° –3
±45° –6
±90° –13
Note: Thedesignandspecicationsaresubjecttochangewithoutnoticeforimprovement.
• Accessories
URL:http://www.toa.jp/
533-06-267-00
Traceability Information for Europe
Manufacturer:
TOACorporation
7-2-1,Minatojima-Nakamachi,Chuo-ku,Kobe,Hyogo,Japan
Authorizedrepresentative:
TOAElectronicsEuropeGmbH
Suederstrasse282,20537Hamburg,Germany
GRIPPLE
®
No.1*(preinstalledonthesafetywire)...............1
GRIPPLE
®
No.2*(preinstalledonthehangingwire)............1
Releasekey(forGRIPPLE
®
)................................................1
Safetywire(5mor16.4ft,ø1.5mmor0.06")......................1
Hangingwire(5mor16.4ft,ø2mmor0.08")......................1
Speakercable(4-coreFPLlistedcable4.6mor15.09ft)....1
*GRIPPLE
®
No.1andNo.2arehangersforsuspendingthespeaker.
