8.2.2. Manual broadcasting screen
Pressing a Selection key that has been set for manual broadcasting displays the manual broadcasting
screen. Press the key again to return to the Home screen.
(7) Key name
Displays the names assigned to the
Selection keys. Executing manual
broadcasting inverts the screen colors and
displays the speaker symbol. A maximum of
32 characters can be displayed.
(8) Selected audio source display
Displays the selected audio source.
(9) Broadcast destination display
Displays information about the preset
broadcast destination. If multicast, the
broadcast destination group name is
displayed. If SIP, the broadcast destination’s
SIP ID or IP address is displayed.
(10) Broadcast destination Icon
The following icons are displayed according
to the broadcast destination:
M1
"M1" or some other multicast
channel number, is displayed if the
broadcast destination is Multicast.
SIP
"SIP" is displayed if the broadcast
destination is SIP.
(11) Chime icon
A chime is sounded whenever this icon
appears.
(12) Status display
Indicates whether or not the selected
broadcast can be executed when the
Remote Microphone is broadcasting in the
background. "Busy" is displayed whenever
a higher priority broadcast is in progress,
and "Ready" is displayed whenever the unit
is in standby mode or when a lower priority
broadcast is in progress.
(13) Chime selector
Chime operation (before and after a
broadcast) can be enabled or disabled by
pressing the
key. The chime can also be
temporarily switched ON or OFF regardless
of whether or not the chime has been
enabled in the key settings.
(14) Control output status display
When the control output is initiated in
conjunction with a broadcast, the current
control output can be checked to conrm
that it is ON or OFF. If linked to the
broadcast, the display turns on with the
start of the broadcast.
(15) Audio source selection
The selected audio source display (8)
switches in the following order with each
depression of the
key. Select the sound
source to be used for manual broadcasting.
MIC REC AUX
MIC: The microphone is selected
and broadcasts are made using
microphone audio.
REC: Recorded audio is selected and
broadcasts are made using recorded
audio.
AUX: AUX is selected and broadcasts are
made using audio input to the AUX
jack.
1
2
3
4
5
6
7
8
9
0
VOLUME
Microphone
Multicast 1
ALL AREA
［
DEST
］
［
SOURCE
］
Ready
［
STATUS
］
CHIME SOURCE
♫
OFF
M1
12 13 14 15
7 8 9
10 11
1
2
3
4
5
1/1
（月）
12:00
6
7
8
9
0
VOLUME
♫
ON
M1
Jan 1 MON
12:00
Microphone
Multicast 1
［
DEST
］
［
SOURCE
］
Broadcasting
［
STATUS
］
ALL AREA
[During manual broadcasting]
[When manual broadcasting is selected]
