8

5. SUSPENDING THE SPEAKER FROM A CEILING (only the T-bracket is used)

TheHX-7BorHX-7WSpeakerSystemcanbesuspendedfromaceilingbyonlyusingtheT-bracket.

Note

Similarly, fix the T-bracket to the end of the

side angle plate on the opposite side.

HX-7B or HX-7W

T-bracket

Spacer ø9.2 (0.36")

(accessory)

Rear bracket

Hex head

bolt M6x12

(accessory)

Side angle plate

Protection cover

Note

Remove the

protection covers

from the side

angle plates

before joining.

1-1

Tightening torque:

5 N·m

J-spacer

(accessory)

1-2

(1) Lightly secure.

(3) Tighten firmly.

(2) Insert.

Flange nut for M6

(accessory)

Hex head

bolt M6x30

(accessory)

Tightening torque:

5 N·m

Tightentheboltssecurely,asinstructedbelow.

Failuretofollowinstructions precisely could result in a falling speaker

andpotentialpersonalinjury.

• Ensurethatallboltsaresecurelyinsertedasfarastheirthreadsgo,

then securely fasten each bolt with a nut.

• Tightenalltheboltswiththedesignatedtighteningtorque.

 Fortightening,useaPhillipsscrewdriver,oropen-orbox-endwrench.

WARNING

Step 1. Attach the T-bracket to the speaker.

Attachwiththespeakersetaboveasshowninthegure.

FixtheT-brackettothespeakeratall3indicatedpositions.

1-1. FixtheT-brackettobothendsofthesideangleplatesofthespeakerfront.

Usethesuppliedbolts(withspringandplainwashers)andspacers.

1-2. FixtheT-brackettothespeaker’srearbracket.

Fixtotherearbracket’sendmosthole.

Usethesuppliedbolt(withspringandplainwashers),J-spacer,andangenut.

Fordetails,refertotheprocedures(1)to(3)asshownbelow.

Note

After tightening the bolt, ensure

thattheJ-spacerisrmlyxed.
