6. DIRECT SPEAKER CEILING MOUNTING (only the T-bracket is used)
AsingleHX-7BorHX-7WSpeakerSystemcanbemountedtoceilingsorbeamsbyonlyusingtheT-bracket.
Note
OnlyoneHX-7BorHX-7Wspeakercanbemounted.Twojoinedspeakerscannotbemounted.
Step 1. MounttheT-brackettotheceilingorbeamusingbolts,etc.
Ceilingorbeammountingboltsandnutsarenotsupplied.
Use nuts and bolts that are appropriate for the ceiling’s or
beam’sstructureandcomposition.Failuretodosomaycause
thespeakertofall,resultinginpersonalinjury.
WARNING
[Mounting dimensions]
Unit:mm
(Front) (Right side)
353 (13.9")
60 (2.36")164.5 (6.48")
0
20 (0.79")
70 (2.76")
120 (4.72")
170 (6.69")
220 (8.66")
0
430 (16.93")
270 (10.63")
320 (12.6")
370 (14.57")
20 (0.79")
70 (2.76")
120 (4.72")
170 (6.69")
220 (8.66")
270 (10.63")
320 (12.6")
370 (14.57")
ø9 (0.35")
(with M8 weld nut)
ø9 (0.35")
(with M8 weld nut)
ø9 (0.35")
(with M8 weld nut)
ø8.5 (0.33")
(16 positions)*
ø8.5 (0.33")
(14 positions)*
Note: Left-side surface same.
*TheseholesnotttedwithM8weldnuts.
