5
Step 5. MountthespeakersystemtotheT-bracket.
Mountthespeakersystemvertically,asshowninthegure.
FixthespeakertotheT-bracketatall3indicatedplaces.
5-1. Fix the T-bracket to both ends of the side angle plates of the speaker front.
Usethesuppliedbolts(withspringandplainwashers)andspacers.
5-2. Fix the T-bracket to the speaker’s rear bracket.
Fix to the rear bracket’s endmost hole.
Usethesuppliedbolt(withspringandplainwashers),J-spacer,andangenut.
Fordetails,refertotheprocedures(1)to(3)asshownbelow.
Spacer ø9.2 (0.36")
(accessory)
T-bracket
Hex head bolt
M6x12(accessory)
Side angle plate
Protection cover
Note
Remove the
protection covers
from the side
angle plates
before joining.
Note
Similarly, fix the T-bracket to the end of the
side angle plate on the opposite side.
J-spacer
(accessory)
Rear bracket
(1) Lightly secure.
(3) Tighten firmly.
(2) Insert.
Flange nut
for M6 (accessory)
Hex head
bolt M6x30
(accessory)
5
-1
5
-2
5
HX-7B or HX-7W
Tightening
torque: 5 N·m
Tightening torque:
5 N·m
[Completed installation]
Mounting adapter (Commercial product)
Mounting base
Angle bracket
T-bracket
Speaker
Note
After tightening the bolt, ensure that
theJ-spacerisrmlyxed.
