Je bekijkt pagina 7 van 8

7

Step 7. TemporarilyxthespeakertotheWallbracket.

Be sure at least two people are employed to mount the speaker

to the wall. If handled by only one person, the speaker could

fall, potentially resulting in personal injury.

wArNINg

7-1. Insert 2 bolts lightly fastening the L- and Mode brackets into the Wall bracket’s uppermost slots from

above.

7-2. Insert 2 bolts lightly fastening the L-bracket’s lower ends into the Wall bracket’s lower slots from the

side.

7-3. Temporarily tighten all 4 bolts.

7-1

7-1

0° mode

15° mode

30° mode

Wall bracket

45° mode

60° mode

Bottom bracket mounting positions

Wall bracket

Bottom bracket

HX-7B-WP

or

HX-7W-WP

8

9

7-2

Mode bracket

Mode bracket

Hex head bolt M10 x 30 with spring

and plain washers (accessory)

Hex head bolt

M10 x 30 with spring

and plain washers

(accessory)

Hex head bolt

partially inserted

Tightening torque

in Step 10: 15 N·m

Tightening torque

in Step 10: 15 N·m

Tightening torque

in Step 10: 15 N·m

Tightening torque

in Step 10: 15 N·m

Step 8. Temporarilyxthespeaker’sBottombrackettotheWallbracket.

Usingthe2suppliedbolts,temporarilyxtheBottombrackettotheWallbracket.TheBottombracket’s

mountingpositionrelativetotheWallbracketwilldifferdependingonthespeaker’sdirectivityangle

mode,asshowninthegureofthepreviouspage.

Step 9. Temporarilyinstallboltstopreventfalls.

Step 10. TightenalltheboltspartiallyinsertedinStep5andSteps7through9tosecurethespeaker.(Tightening

torque:5N·mforboltsinsertedinStep5,and15N·mforboltsinsertedinSteps7through9)

Beforetighteningbolts,besuretoconrmthatexcessiveforceisnotappliedtothesebolts.

Step 11. Attach safety wires for protection against falls.

Regardingtheattachingmethodofsafetywires,refertotheinstructionmanualsuppliedwithHX-7

series speaker.
