5
Step 3. (WhenmountingtheMT-200Matchingtransformer)
MounttheMT-200tothemodebracket.
Usethesuppliedboltsandnutstomount,as
shown in the figure at right.
For MT-200 wiring, refer to the instruction
manuals suppliedwiththeMT-200andthe
HX-7Seriesspeaker.
Note
To ensure the MT-200’s waterproong
capability, install it so that the tilt of its top
surfaceiswithin45ºoftheverticalplane.
MT
MT
Nut for M8 (accessory)
MT-200
Matching transformer
Mode bracket
Hex head bolt M8 x 15 with
spring and plain washers
(MT-200's accessory)
Tightening torque:
8 N·m
Top surface
MT-200
Matching transformer
45°
45°
UP
Step 4. Mount the T-bracket to the speaker system.
Mountthespeakersystemvertically,asshowninthegurebelow.
Fix the T-bracket to the speaker at all 3 indicated places.
4-1. Fix the T-bracket to both ends of the side angle plates of the speaker front.
Usethesuppliedbolts(withspringandplainwashers)andspacers.
4-2. Fix the T-bracket to the speaker’s rear bracket.
Fix to the rear bracket’s endmost hole.
Usethesuppliedbolt(withspringandplainwashers),angenut,andJ-spacer.
For details, refer to the procedures (1) to (3) as shown below.
Spacer ø9.2 (0.36")
(accessory)
Rear bracket
Hex head
bolt M6x12
(accessory)
Side angle plate
Protection cover
Note
Remove the
protection covers
from the side
angle plates
before joining.
4-1
Note
Similarly, fix the T-bracket to the end of the
side angle plate on the opposite side.
HX-7B-WP or HX-7W-WP
T-bracket
Tightening torque:
5 N·m
J-spacer
(accessory)
4-2
(1) Lightly secure.
(3) Tighten firmly.
(2) Insert.
Flange nut for M6
(accessory)
Hex head
bolt M6x30
(accessory)
Tightening torque:
5 N·m
Note
After tightening the bolt, ensure
thattheJ-spacerisrmlyxed.
