6
Step 5. Mount the Bottom bracket to the speaker system.
Securethebrackettemporarilyusingthesuppliedboltsandangenuts,theninserttheJ-spacer.
Bottom bracket
HX-7B-WP or HX-7W-WP
Flange nut for M6
(accessory)
Hex head bolt
M6 x 30 with spring
and plain washers
(accessory)
Rear bracket
J-spacer
(accessory)
Tightening torque
in Step 10: 5 N·m
Step 6. Mount the Wall bracket to the wall.
Useatleast8bolts(4top,4bottom)tomounttothewall.
Notes
• Makesurethattwooftheuppermostandlowermostmountingholesare
xedtothewallwithbolts,etc.
• Securewithagoodbalanceofboltsinbothleftandrightmountingholes.
60
(2.36")(2.36")(2.36")
(7.72")
(2.36")(2.36")(2.36")
6060196.2606060
70
70
(2.76")
(2.76")
Must be used.
Must be used.
[Wall mounting dimension]
Bolts and nuts for mounting the bracket on the wall are not supplied.
Useboltsandnutsthatareappropriateforthewall’sstructureand
composition. Failure to do so may cause the speaker to fall, resulting
in material damage and possible personal injury.
wArNINg
Note
To ensure ample work space during construction, keep the Wall bracket
atleast0.6m(24")awayfromtheceilingand1m(40")fromtheleftand
right walls.
Unit:mm
1 m (40")
or more
1 m (40")
or more
0.6 m (24")
or more
Ceiling
Wall Wall
