2
• Avoid touching the bracket’s sharp metal edge to
preventinjury.
• Donotplaceheavyobjectsonthebracketasthis
may cause the speaker to fall or break which may
result in personal injury and/or property damage.
In addition, the object itself may fall off and cause
injuryand/ordamage.
• Donotstandorsiton,norhangdownfromtheunit
as this may cause the speaker to fall down or drop,
resultinginpersonalinjuryand/orpropertydamage.
• Havethebracketcheckedperiodicallybytheshop
from where it was purchased. Failure to do so may
result in corrosion or damage to the bracket that
could cause the speaker to fall, possibly causing
personal injury.
Indicates a potentially hazardous situation which,
if mishandled, could result in moderate or minor
personalinjury,and/orpropertydamage.
CAUTION
2. GENERAL DESCRIPTION
TheHY-MS7SeriesbracketsareintendedformountingtheHX-7B-WPorHX-7W-WPSpeakerSystemtothe
wallunderoutdooreaves.ThesebracketsalsohaveprovisionformountingtheMT-200MatchingTransformer*
directly to this bracket.
*Thismatchingtransformerisusedtoconvertlowimpedanceintohighimpedance100Vlineor70Vline.
3. NOTES ON INSTALLATION
• Observethefollowinginstructionswheninstallingthespeakersystem.
Failuretodosocouldadverselyaffecttheirintendedweather-proof
and splash-proof capabilities, leading to malfunction.
· Install the speaker system in locations not exposed directly to rain,
suchasundertheeaves.
· All speaker modules must point downward from the horizontal.
• Wheninstallingthespeaker,ensureallrearanglebars*aresettothe
samedirectivityanglemode.Ifdifferentdirectivityanglemodesare
combined,theHY-MS7Series’bottombracketcannotbemountedto
the wall bracket.
* Thebracketbarsusedtojoinindividualspeakermodulesattherear
ofthe speaker.For instructions on changing the directivity angle,
refertotheinstructionmanualsuppliedwiththeHX-7B-WPorHX-
7W-WPspeaker.
• Horizontalspeakerinstallationnotpossible.
4. MOUNTING DIAGRAM
[Component disassembly] [Completed installation]
Horizontal
[Vertical installation]
T-bracket
L-bracket
HX-7B-WP or HX-7W-WP
Speaker System
Mode bracket
Wall bracket
Bottom bracket
