Suspension hole
Suspension bracket
(Speaker's accessory)
Hex head bolt M6 x 20
(with spring and plain washers,
speaker's accessories)
Tightening torque:
3 N·m
[Installation method of suspension brackets]
Tighten the bolts securely, as instructed below. Failure to follow
instructions precisely could result in a falling speaker and potential
personal injury.
• Ensurethatallboltsaresecurelyinsertedasfarastheirthreadsgo,
then securely fasten each bolt with a nut.
• Tighten all the bolts with the designated tightening torque. For
tightening,useaPhillipsscrewdriver,oropen-orbox-endwrench.
WARNING
Beforeinstallingsuspensionbrackets,layoutaprotectivesheet,corrugatedcardboardorothersoftmaterialon
aatsurface,andperformallworkonthe2speakerswiththeirfrontbafesfacingdownward.
Step 1. Removethesideangleplatebolts(indicatedbythearrowsinthegurebelow).
Step 2. Usingtheboltssuppliedwiththespeaker,tightenthesuspensionbracketsandsideangleplates.
Combinethebracketssuppliedwiththe2speakers,andattachthemwiththesuspensionholesfacing
outward,asshowninthegurebelow.
Note:DonotusetheboltsdetachedinStep 1.
