5
3-1
3-1
3-2
Flange nut (for M6, accessory)
Rear bracket of speaker module B
Rear bracket of speaker module A
Speacer (black, accessory)
Rear angle bar of this bracket
Hex head bolt M6 x 25
(with spring and plain washers, accessory)
Tightening torque:
3 N·m
Hex head bolt M6 x 25
(with spring and plain washers, accessory)
Tightening torque:
3 N·m
Fulcrum for the angle adjustment
Rear angle bar of this bracket
Angle adjustment holes
0° mode
15° mode 30° mode
45° mode
[Completed installation (0° mode)]
3-1. AttachtheHY-CN7bracket'srearanglebartotherearbracketofspeakermoduleA.
Usethesuppliedhexheadboltsandnuts.
Fit thespacer (black)into the larger hole in the rear angle bar, then with the angle bar positioned
betweenthe2platesofrearbracketA,andwithholesaligned,inserttheboltthroughtherightmost
holeintherearbracket,andfastenwiththenut.
Notes
• Thispositionwillactasthefulcrumforangleadjustment.Besurethattheanglebarisxedinthe
position indicated in the illustration below. If xed in a different position, the angle mode will not
conformwiththespeciedvalue.
• Besureaspacer(black)isttedintothelargerholeintherearanglebar.
3-2. AttachtheHY-CN7Seriesbracket'srearanglebartotherearbracketofspeakermoduleB.
Usethesuppliedhexheadboltandnut.
Aligntherearanglebarwiththedesireddirectivityanglemodeposition,theninsertaboltandfasten
with a nut.
Thegureshowsamountingexamplewith0°modeselected.
Notes
• Aspacerisnotused.
• Whena60°modeisdesired,usetheoptionalHY-60DSeriesSpeakerAngleAdjustmentBrackets.
Fordetails,refertotheinstallationmanualenclosedwiththeHY-60DSeriesbrackets.
Note
Useamethodsimilartothatdescribedin Steps 1 – 3above, evenwhenjoining three orfourHX-7Series
Speaker Systems.
