7
6. DIMENSIONAL DIAGRAM
Unit : mm
350 (13.78")
200 (7.87")
280 (11.02")
90 (3.54") 400 (15.75")
40 (1.57")
[Right side]
[Left side]
[Front]
[Rear]
[Top]
230 (9.06")
6-M6
2-M6
90 (3.54")
7. SPECIFICATIONS
Model No. FB-08BT FB-08WT
Enclosure Bass-reex type
Power Handling Capacity*
1
Rated noise power: 120 W (8 Ω)
Continuous program: 240 W (8 Ω)
Rated Input 120 W (100 V line, 70 V line)
Rated Impedance 8 Ω
100 V line: 83 Ω (120 W), 167 Ω (60 W)
70 V line: 50 Ω (100 W), 83 Ω (60 W), 167 Ω (30 W)
Sensitivity 84 dB (1 W, 1 m) at installation in free sound eld
90 dB (1 W, 1 m) at installation in 1/2 free sound eld
Frequency Response 45 – 300 Hz, –10 dB at installation in 1/2 free sound eld
Speaker Component 20 cm (8") cone-type
Input Terminal M4 Screw terminal, distance between barriers : 9 mm (0.35")
Operating Temperature –10 to +50 °C (14 to 122 °F)
Installation Environment Indoor installation
Finish Enclosure MDF, black*
2
, paint MDF, white*
3
, paint
Grille Surface treated steel plate,
black*
2
, paint
Surface treated steel plate,
white*
3
, paint
Dimensions 200 (w) x 350 (h) x 400 (d) mm (7.87" x 13.78" x 15.75")
Weight 16 kg (3.53 lb)
*
1
Rated noise power is dened by IEC60268-5. Continuous program is 3 dB above Rated noise power.
*
2
RAL 9011 equivalent
*
3
RAL 9016 equivalent
Note: The design and specications are subject to change without notice for improvement.
