4
4. CONNECTION
This Subwoofer system supports both high impedance application
and low impedance application.
After setting the impedance on the Subwoofer system’s rear-mounted
input terminal section as shown below, make the connection to the
amplier.
Also, pull out the cables from the notch.
4.1. When using high impedance connection
To maximize the performance of this speaker and achieve optimal sound quality, please use the following
recommended ampliers.
Recommended ampliers
(option)
DA-250DH CE301, DA-250DH CE-GB, DA-250DH CE-AU, DA-250DH CU
DA-250FH CE301, DA-250FH CE-GB, DA-250FH CE-AU, DA-250FH CU,
DA-250FH KR, DA-250FH TW
DA-500FH CE301, DA-500FH CE-GB, DA-500FH CE-AU, DA-500FH KR
A-5012 1CE, A-5012 4CE
Note
If ampliers other than the recommended ones are used, the following issues may occur.
• Decreased sound quality:
The speaker’s performance may not be fully realized, leading to degraded sound quality.
• Sound interruptions and volume uctuations:
The amplier’s protection function may activate, causing sound interruptions or unstable volume levels.
To maintain the longevity and performance of both the speaker and the amplier, we strongly recommend using
the suggested ampliers.
Please use the recommended ampliers correctly according to the instruction manuals supplied with the
ampliers.
Step 1. Insert the short piece to the position as shown in the
gure.
Tip
The gure shows the factory-set position of the short
piece.
Step 2. According to the input power to use, connect the
cables from the amplier to the COM terminal and the
corresponding input terminal.
Notes
• When using the speaker with high impedance 100
V line, never connect it to the
(Not allowed)
terminal. As doing so may cause damage to the
speaker.
• Depending on the relative installation position of
this Subwoofer speaker to the speaker system (p. 3),
the bass may be attenuated. In such cases, try to
reverse the speaker cable connections between
the COM and power output terminals, and check
the output sound from the speakers. Then, use the
connection that produces the louder bass.
11
2
2
Short piece
Input terminal section
Notch
Input terminal
section
Rear
