9.3. F-08BT-WP-UE, F-08WT-WP-UE
Model No. F-08BT-WP-UE F-08WT-WP-UE
Standards Certified to the European Standard EN 54-24: 2008
Loudspeaker for voice alarm systems for fire detection and fire
alarm systems
DoP Number: 24-105
Certificate No.: 1438-CPR-1053
Enclosure Sealed type
Power Handling Capacity*
1
Rated noise power: 90 W (8 Ω)
Continuous program: 180 W (8 Ω)
Rated Input 60 W (100 V line, 70 V line)
Rated Impedance 8 Ω
100 V line: 170 Ω (60 W), 330 Ω (30 W), 670 Ω (15 W), 3.3 kΩ (3 W),
70 V line: 83 Ω (60 W), 170 Ω (30 W), 330 Ω (15 W), 670 Ω (7.5 W),
3.3 kΩ (1.5 W)
Sensitivity 90 dB (1 W, 1 m) (1 – 10 kHz, pink noise)
Speaker Component Low frequency: 20 cm (8") PP cone-type
High frequency: 25 mm (1") dome tweeter
Frequency Response 70 Hz – 20 kHz, –10 dB at installation in 1/2 free sound eld
Crossover Frequency 3 kHz
Directivity Angle Horizontal: 100°, Vertical: 100°
Compliance/Certications EN 54-24:2008, UL 1480A (UEAY (Outdoor use))
IP Code IP65
Installation Environment Indoor installation, outdoor installation
EN 54-24 specications
Sensitivity 75 dB (1 W, 4 m)
Max. SPL 92 dB (60 W, 4 m)
Coverage Angle (–6 dB) Horizontal: 170° (500 Hz), 130° (1 kHz), 100° (2 kHz), 110° (4 kHz)
Vertical: 150° (500 Hz), 130° (1 kHz), 100° (2 kHz), 90° (4 kHz)
Environmental Type B (outdoor applications)
IP Code IP33C
Operating Temperature –10 to +50 °C (14 to 122 °F)
Input Terminal M4 screw terminal, distance between barriers : 9 mm (0.35")
Applicable Cable Cabtyre cable: ø6 – 10 mm (0.24 – 0.39'')
Solid wire, Twisted wire: 0.3 – 3.3 mm
2
(AWG 22 – 12)
Finish Enclosure HIPS, black*
2
, paint HIPS, white*
3
, paint
Grille Aluminum, black*
2
, paint Aluminum, white*
3
, paint
U bracket Stainless steel, t3, black*
2
, paint Stainless steel, t3, white*
3
, paint
Speaker bracket Stainless steel, t3, black*
2
, paint Stainless steel, t3, white*
3
, paint
Dimensions 251 (w) x 392 (h) x 216 (d) mm (9.88" x 15.43" x 8.5")
Weight 5.5 kg (12.13 lb)
*
1
Rated noise power is dened by IEC60268-5. Continuous program is 3 dB above Rated noise power.
*
2
RAL 9011 equivalent
*
3
RAL 9016 equivalent
Note: The design and specications are subject to change without notice for improvement.
• Accessories
U bracket ....................................................................................... 1
Speaker bracket ............................................................................ 2
Machine screw M8 x 12 (with plain washer and spring washer) ... 4
Machine screw M5 x 20 (with plain washer and spring washer) ... 4
Terminal cover ............................................................................... 1
Tapping screw 4 x 12 ..................................................................... 4
