8
Example :
Step Two :
According to the deviation value and the reference below, add
or subtract the corresponding shim to complete the flange back
adjustment.
If the scale pointer points to 3 spaces in the direction of the
closest focusing distance, the deviation value is -3.
If the scale pointer points to 5 spaces in the direction of infinity,
the deviation value is +5. At this situation, the shim value of "+4"
needs to be added to the shim value of "+1".
Simera-C Adjustment Reference（mark value : 1m/3'6）
focal
length
deviation value
-5
-4
-3
-2
-1
0
+1
+2
+3
+4
21mm
28mm
35mm
50mm
75mm
-0.21
-0.2
-0.22
-0.27
-0.48
-0.18
-0.15
-0.18
-0.23
-0.35
-0.14
-0.11
-0.14
-0.18
-0.28
-0.09
-0.08
-0.1
-0.12
-0.19
-0.04
-0.04
-0.04
-0.06
-0.1
0
0
0
0
0
0.08
0.07
0.07
0.1
0.15
0.14
0.1
0.12
0.17
0.27
0.17
0.15
0.18
0.23
0.36
0.21
0.2
0.23
0.28
0.47
1m or 3′6
1m or 3′6
1m or 3′6
1m or 3′6
1m or 3′6
recommend
Mark value
Note :
Shim adjustment: "+" means adding shims, and "-" decreasing shims. Data in
this sheet might have deviation and just for reference. Please adjust based
on actual situation.
