Back to Contents
7
2. Flange Back Adjustment
Ready your subject and calibration tool. You can use a "Star
Chart", or other high-resolution black-and-white objects;
download the "Back focus Calibration Tool for Prime Lens"
(short for “Calibration Tool”) on the official website.
Note :
Step One :
Rotate the focus ring until the image to its clearest. Take the
horizontal line in the middle of the calibration tool as the reference
and observe the position of the deviating scale pointer to get the
number of horizontal lines.
The direction of infinity indicates positive deviation value.
The direction of the closest focusing distance indicates negative
deviation value.
If there are more than 4 horizontal lines, add or subtract the
corresponding value.
Step Four :
Set the object 1m(or 3’6) away from the camera sensor plane,
and adjust it to the center of the whole image.
Set the object 1m(or 3’6) away from the camera sensor plane,
and adjust it to the center of the whole image.
Please adjust as the following steps:
T1.5 Aperture
Φ
1m/3’6
