H-HDCOAX-1/2/4/6/8
Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com
HDMI Encoding Section
Input
Interface
HDMI*4
Video
Encoding
MPEG2
Input
Output
480@59.94/60i
480@30p
576@50i
576@25p
720@50/59.94/60p
720@25/30p
1080@50i
1080@25p
1080@59.94/60i
1080@30p
1080@50p
1080@25p
1080@59.94/60p
1080@30p
Bit-rate
2.000~20.000 Mbps
Rate Control
VBR
Aspect Ratio
16 :9
Audio
Encoding
MPEGI layer 2, AAC, AC3
Sample rate 48KHz
Bit rate
MPEGI layer 2（192kbps）
AAC（VBR）
AC3（128kbps）
DVB-C Modulator Section
Standard
J.83A (DVB-C), J.83B
MER
≥35dB
RF frequency
100-1000MHz, 1KHz step
RF output level
-63~ -16dBm (44~91 dBµV),
1dB step
Symbol rate
3.000~7.000Msps adjustable
J.83A
J.83B
Constellation
16/32/64/128/256QAM
64/
256QAM
Bandwidth
8M
6M
DVB-T Modulator Section
Standard
DVB-T COFDM
Bandwidth
2M, 3M, 4M, 5M, 6M, 7M, 8M
Constellation
QPSK, 16QAM, 64QAM
Code rate
1/2, 2/3, 3/4, 5/6, 7/8
Guard Interval
1/32, 1/16, 1/8, 1/4
Transmission
Mode:
2K, 8K
MER
≥35dB
RF frequency
100-1000MHz, 1KHz step
RF output
level
-63~ -16dBm(44~91 dBµV), 1dB step
ISDB Modulator Section
Standard
ARIB STD-B31
Constellation
QPSK, 16QAM, 64QAM
Guard Interval
1/32, 1/16, 1/8, 1/4
Transmission Mode
2K, 4K, 8K
Code rate
1/2, 2/3, 3/4, 5/6, 7/8
RF frequency
100~1000MHz, 1KHz step
RF output level
-63~ -16dBm(44~91 dBµV), 1dB
step
ATSC Modulator Section
Standard
ATSC A/53
Constellation
8 VSB
RF output level
-63~-16dBm (44~91dBµV),1dB
step
MER
≥35dB
RF frequency
100~1000MHz, 1KHz step
RF output level
-63~ -16dBm(44~91 dBµV), 1dB
step
System
Management
Web
Language
English
Upgrade
Web update
General
Power supply
AC 100V±10%, 50/60Hz or AC
220V±10%, 50/60Hz
Dimensions
482*328*44.5mm
Temperature
0~45℃(operation),-20~80℃
(storage)
