HDMI/SDI-QAM-IPLL
Thor Fiber Tel: (800) 521-84 Email: sales@thorfiber.com https://thorbroadcast.com/ http://www.thormodulators.com/
Intro – Gui & VCT
Thor Broadcast ships from our facility in Los Angeles with a preloaded NMS GUI firmware
Generally the IP address will be 192.168.0.136 : this goes into any internet browser URL line
Once you’re at the login screen default username and admin passwords are both: admin
***If you do not have a green light
at the bottom of this screen as
shown to the left here, that means
the unit is not reading the
input(red light) which means that
your resolution is above or below
the units threshold of 720 to 1080
(could be 480 if using composite
inputs)
The Welcome Screen show above has general information of your working encoder
On the left hand side you can quickly switch to Thor’s Parameters and System Control
Input 1 reflects the first TWO HDMI inputs 1 & 2
Input 2 reflects the next TWO HDMI inputs 3 & 4
In this example – we have inserted 4 HDMI inputs into our unit (DVD/BLURAY)
