HDMI/SDI-QAM-IPLL
Thor Fiber Tel: (800) 521-84 Email: sales@thorfiber.com https://thorbroadcast.com/ http://www.thormodulators.com/
Figure-1
4.2 Operation
Welcome
When we confirm the login, it displays the WELCOME interface.
Figure-2
Input 1
From the menu on the left side of the webpage, click “Input 1”, it displays the information of the
programs from the first 2 inputs you are encoding.
Cllick any item here to
enter the corresponding
interface to check
information or set the
parameters.
Displays the
signal source
inputs and their
data rate. If the
Green circles
appear you’re
good, if they are
RED you most
likely have
resolution
problem.
