HDMI/SDI-QAM-IPLL
Thor Fiber Tel: (800) 521-84 Email: sales@thorfiber.com https://thorbroadcast.com/ http://www.thormodulators.com/
3.1.2 Initial Status
After powering on the device，it will take a few seconds to initialize the system
DVB-C: indicates the modulation standard of this device.
A/B/C/D: indicates the 4 carrier outputs
XXX.XX MHz: Indicates the current output frequency (Range: 30~999MHz) of the 4 carriers
output.
X.XX Mbps: Indicates the encoding bitrate of each encoding output respectively.
3.2General setting for Main Menu
By pressing the “Lock” key on the front panel, enter the main menu. The LCD will display the
following pages:
Press UP/DOWN buttons to specify menu items, and then press ENTER to enter the submenus as
below:
1) Status
Press Enter to enter “Status” and it displays the working time duration of the device
2) Input Sets
Under this submenu, the LCD will show “2.1 Input 1”, “2.2 Input 2” and “2.3 Input 3”.
Start up…
Start OK…
DVB-C A XXX.00MHz
P1 X.XXMbps P2 X.XXMbps
1 Status
2 Input Sets
1 Status
2 Modulator
3 Modulator
4 TS Config
5 Network
6 System
1.1 Uptime
Uptime
2 Days-10:30:20
2 Days-10:30:20
2.1 Input 1
2.2 Input 2
2.3 Input 3
