HDMI/SDI-QAM-IPLL
Thor Fiber Tel: (800) 521-84 Email: sales@thorfiber.com https://thorbroadcast.com/ http://www.thormodulators.com/
SDI Encoding Input
Input
Option 1:SDI*1
Option 2:SDI*2
Encoding
MPEG2; MPEG4 AVC/H.264
Bitrate
1-19.5Mbps
Resolution
1920*1080_60P, 1920*1080_50P,
(-for MPEG4 AVC/H.264 only)
1920*1080_60i, 1920*1080_50i,
1280*720_60p, 1280*720_50P
720*480_60i, 720*576_50i
Low Delay
Normal, Mode 1, Mode 2
Rate Control
VBR/CBR
Chroma
4:2:0
Aspect Ratio
16:9,4:3
Audio
Encoding
MPEG1 Layer II ,MPEG2-AAC, MPEG4-AAC
and Dolby Digital AC3 2.0( Optional)
Sample rate
48KHz
Bitrate
64/96/128/ 192/256/320kbps
Modulator Section
DVB-C
Standard
J.83A (DVB-C), J.83B, J.83C
MER
≥43dB
RF frequency
30~960MHz, 1KHz step
RF output level
-30~ -10dbm (77~97 dbµV), 0.1db
step
Symbol rate
5.000~9.000Msps adjustable
RF Out
1*DVB-C;
4*DVB-C carriers combined output
J.83A
J.83B
J.83C
Constellation
16/32/64/1
28/256QAM
64/ 256
QAM
64/
256
QAM
Bandwidth
8M
6M
6M
General
System
Local interface
LCD + control buttons
Remote management
Web NMS
Stream Out
2 ASI out (BNC type);
IP (MPTS/SPTS) out (RJ45, 100M)
NMS interface
RJ45, 100M
Language
English
Physical
Specifica
tion
Power supply
AC 100V~240V
Dimensions
482*300*44mm (19” rack)
267*250*44mm (portable)
Weight
4.5 kg (19” rack)
2.5 kg (portable)
Operation
temperature
0~45℃
