4. Designation codes, drawings and models

Each product has a specific identification code, the designation code. The designation

code can be found on the data badge. See Service & questions for the location of the data

badge. The different positions of the code stand for different variations of the refrigerator.

In these instructions, the designation will be used as reference.

Table 1: Designation example

T1152 E – N 303 AD 211 R 28 CI

Refri-

gerator

model

Refri-

gerator

version

Market Type of

foamed

cabinet

Type of

cooling

unit

Type of

door

Hinge

posi-

tion

Type of

control

panel

Type of

com-

munic-

ation

Table 2: Available drawings and models

Model* 2D drawings 3D files Door panels

T1090E LE1610 LE1611 LE1494

T1090EX LE1566, LE1612 LE1613 LE1494

T1152E LE1593 LE1594 LE1496

T1156E LE1595 LE1596 LE1548

The 2D drawings and door panels drawings are available upon request, 3D files are only

available for the professional builder.

* Not all models are available for the Aftermarket (A-market in Table 1: Designation

example)

6
