MIX 2 series RMG 8 T / RME 8 T actuators
6 Typical applications
These typical applications are designed to aid planning.
They have no claim to completeness and may be adjusted or extended as desired.
6.1 2x switching with push button interface (switch actuator)
2 push buttons are connected to a TA 2 push button interface and they control 2 channels
on the RMG 8 T.
6.1.1 Devices:
• RMG 8 T (Order no. 4930200)
• TA 2 (Order no. 4969202)
6.1.2 Overview
Figure 1
6.1.3 Objects and links
Table 32
No.
TA 2
No.
RMG 8 T
Comment
Object name
Object name
0 Channel 1 switching 0
RMG 8 T channel C1
Switch object
-
3 Channel 2 switching 10
RMG 8 T channel C2
switch object
-
Version: May-14 (Subject to change) Page 69 of 87
