MIX 2 series RMG 8 T / RME 8 T actuators
5.3.5.10 The "Scenes" parameter page
This page appears when the Scenes are activated on the Configuration options parameter
page.
Each channel can participate in up to 8 scenes.
Table 20
Designation
Values
Description
Lock telegram for scenes
Lock with ON telegram
0 = Enable
1 = Lock
Lock with OFF telegram
0 = Lock
1 = Enable
Note: With this setting the scenes are
always locked immediately after reset or
download.
All channel scene
statuses
Overwrite on download
A download deletes all scene memories
in a channel, i.e. all previously taught in
scenes.
When a scene number is called, the
channel assumes the configured Status
after download (see below).
See appendix: Teach in scenes without
telegrams
Unchanged after download
All previously taught in scenes are
saved.
However, the scene numbers the channel
should react to can be changed (see
below: Channel reacts to).
Participation in central
scene object
No
yes
Should the device react to the central
scene object?
Channel reacts to
No scene number
Scene number 1
Scene number 63
First of the 8 possible scene numbers the
channel is to react to.
Status after download
Off
On
New switching status that the selected
scene number is to be allocated to.
Only possible if the scene statuses are to
be overwritten after download.
Permit teach in
No
Scenes can only be called up.
Yes
The user can both call up and teach in or
amend scenes.
Version: May-14 (Subject to change) Page 47 of 87
