1 [LEVEL] | Rotary control for adjusting the overall volume of the device (sum of all input signals)
2 [POWER] | Status LED. This LED lights up when the device is on.
3 [LIMIT] | These LED chains indicate the level of the sum signal. Keep the level in the green or max yellow range. If the red
LEDs (CLIP) light up, the sum signal is clipping. In case of clipping, turn back the [LEVEL] master control until the red LEDs
no longer light up.
4 [EFX LEVEL] | Rotary control for adjusting the signal portion sent to the internal eects section
5 Rotary control for selecting one of the 16 pre-set DSP eects
6 Receiver for the infrared remote control
7 Media player with buttons for playing MP3 les
[MODE] | Button for selecting the signal source (Bluetooth®, USB, AUX).
| Button for starting/pausing playback (Bluetooth®, USB)
| Button for selecting the previous track. Press and hold the button for three seconds to decrease the volume (Blue‐
tooth®, USB).
| Button for selecting the next track. Press and hold the button for three seconds to increase the volume (Bluetooth®,
USB).
8 Display
9
| Signal input for channel [9/10], designed as USB connection socket.
The capacity of the connected USB ash drive must not exceed 8 GB.
10 [AUX] | Signal input for channel [9/10], designed as 3.5-mm jack socket.
For the input for channel [9/10], the 3.5-mm jack socket has priority if the 3.5-mm jack socket and the cinch sockets are
used at the same time. The signal from the cinch sockets is muted in this case.
11 [LEFT]/[RIGHT] | Signal input for channel [9/10], designed as cinch sockets
For the input for channel [9/10], the 3.5-mm jack socket has priority if the 3.5-mm jack socket and the cinch sockets are
used at the same time. The signal from the cinch sockets is muted in this case.
12 [L/MONO]/[RIGHT] | Line level for channels [5/6] and [7/8], designed as 6.35-mm jack sockets
13 [LINE OUT] | Signal output for connecting an active speaker, designed as 6.35-mm jack sockets
14 Microphone/line input for channels [1]…[4], designed as XLR/jack combo socket
15 [MIC]/[GUITAR]/[LINE] | Slider for selecting the input sensitivity for channels [1]…[4]-
Select [MIC] to connect a microphone, [GUITAR] to connect a high-impedance instrument (e.g. a guitar) or [LINE] to con‐
nect a device with a line signal (e.g. keyboard or player).
16 [FX] | Rotary control for controlling the signal portion of the internal eect of the respective channel
17 [LOW] | Rotary control for adjusting the low frequencies of the respective channel
18 [HIGH] | Rotary control for adjusting the high frequencies of the respective channel
19 [LEVEL] | Rotary control for adjusting the volume of the respective channel
20 [PEAK] | Status LED. The LED ashes red if the signal of the corresponding input is too strong. In case of an overload,
reduce the volume of the respective input.
