4.1 Pin assignment
You may use XLR and jack connectors with either balanced or unbalanced pinout. Below you
will nd an overview of the dierent options.
XLR panel sockets are provided for signal inputs. XLR panel plugs are provided for signal out‐
puts. The gure and the table show the XLR pin assignment.
Balanced pinout:
1 Ground
2 Positive signal (+)
3 Negative signal (–)
XLR connections for signal
inputs/outputs
Installation
active speaker
16
