1 [PEAK] | This LED indicates that the permitted input level has been exceeded. In that

case, reduce the volume of the relevant channel.

2 [BASS BOOST | FLAT | 120Hz HPF] | Preset switch:

[BASS BOOST] | Increasing the low frequencies.

[FLAT] | Even frequency response.

[120Hz HPF] | Attenuation of frequencies below 120 Hz (high pass lter).

3 [TREBLE] | Control for increasing or decreasing the high frequencies by up to 15 db

each.

4 [BASS] | Control for increasing or decreasing the low frequencies by up to 15 db.

5 [MIX OUT] | Line output for the mixed input signal from both channels.

6 [POWER ON/OFF] | Use this mains switch to turn the device on or o.

7 [INPUT] | Power Twist connection for the power supply of the device.

8 [OUTPUT] | Power Twist connection for powering another device.

9 [CH1 IN | CH2 IN] | Signal input, designed as XLR / 6.35-mm jack combo socket.

10 [LINE - MIC] | Switch for toggling the sensitivity of the respective input between

microphone and line level.

11 [CH1 VOL | CH2 VOL] | Volume control for the respective channel.

Achat 112 & 115 MA MKII

OUTPUT

100-240V~50/60Hz

INPUT

100-240V~50/60Hz

max. 12A

Connections and controls

Achat 110 MA MKII , Achat 112 MA MKII, Achat 115 MA MKII

Active Speaker
