67
68
69
G
click
1
R
L
1
2
3
3. Slide C5 all the way back
until you hear a click.
1. Place subassembly G,
making sure to align the
grooves as shown.
C5
F1
F2
Before
Side view
Side view
After
2. To lock in place, slide back
until you hear a click.
2
Notice there are R (right) and
L (left) letters on the parts.
1. Press down on the platform.
2. Place the hooks of C5 into the slots
as shown.
click
70
71
72
J
click
1
3
2
1
2
Press B2 down until you hear
a click.
3. Use both hands to push subassembly
J back until you hear a click.
1. Line up all six holes of C2 as
shown and press down.
2. Slide C2 back to lock in place.
1. Line up the three holes on the right
side of subassembly J as shown.
2. Line up the other three holes and
press down all the way.
C2
B2
click
click
17
Assembling the Ultra Bionic Blaster
