Checklist:

No. Description Qty. Part No.

1 Anchor pin, black 20

7344-W10-C2D

2 Joint pin, blue 3

7413-W10-T1B

3 Connector pin, gray 10

1187-W10-E1S2

4 Long connector, gray 2

7066-W10-A1S

5 Washer 1

R12#3620

6 Axle, 35 mm 2

7413-W10-O1D

7 Axle, 60 mm 2

7413-W10-M1D

8 Axle, 70 mm 2

7061-W10-Q1D

9 1-hole connector 2

7430-W10-B1D

10 3-hole dual rod with pegs 1

7404-W10-B1S2

11 3-hole cross rod 2

7026-W10-X1Y

12 3-hole wide rounded rod 4

7404-W10-C1D

13 5-hole flat rounded rod 2

7443-W10-C1S1

14 5-hole rod 3

7413-W10-K2SK

15 5-hole cross rod 1

7413-W10-R1Y

16 5-hole dual rod 4

7413-W10-W1SK

17 7-hole flat rounded rod 4

7404-W10-C3D

18 7-hole wide rounded rod 4

7404-W10-C2D

19 Square frame 2

7413-W10-Q1D

20 3x13 dual frame 2

7406-W10-A1S

21 5x3 L-rod, right 1

7066-W10-C1S

No. Description Qty. Part No.

22 5x3 L-rod, left 1

7066-W10-C2S

23 Small gear 2

7026-W10-D2S1

24 Medium gear 2

7408-W10-D2S

25 Medium spindle gear 1

7408-W10-D1Y

26 Worm 2

7344-W10-A1SK

27 Large annular gear 2

7066-W10-F1S

28 Mini gear 4

7066-W10-F3S

29 Large pulley wheel 2

7344-W10-N1Y1

30 Large O-ring 2

R12-09S

31 Motor and arm assembly, left 2

7066-W85-A1

32 Motor and arm assembly, right 2

7066-W85-A2

33 HD Camera 1

7066-W85-C-US

34 Controller box 1

7066-W85-B

35 Lithium battery (3.7V) 1

7066-W85-D

36 LED light 1

7066-W85-E

37 Set of 4 propellers 2

E41#7066

38 Small part separator tool 1

7066-W10-F2S

39 Part separator tool 1

7061-W10-B1Y

40 Propeller shield ring 4

7066-W10-E1D

41 Micro USB cable 1

E30#7066A

42 Storage case (not pictured) 1

K40#7066

Robotics: Smart Machines — 5-in-1 Buildable Drone

TABLE OF CONTENTS

Kit Contents ..................................... Inside front cover

Table of Contents ........................................................ 1

Safety Information ....................................................... 2

Important Information and Tips ................................. 3

ASSEMBLY STARTS ON PAGE 8

Downloading and Using the App .......................... 5

Camera Quadcopter Drone ................................. 8

Flying Your Camera Drone .............................. 11

Robotic Camera Car ......................................... 13

360-Degree Camera .......................................... 17

Turntable Camera ............................................ 21

Hands-Free Camera Mount .............................. 24
