EXPERIMENT 3
HERE’S HOW
Instead of the normal 30 pumps to fill the
air tank, use only 15 pumps. Then try to
pick up one of the cylinders. Repeat this
experiment
using 30 pumps
and then 40
pumps.
Compare the
speed and
strength of the
grabber each
time.
Pneumatic strength
ROBOTIC CLAW
HOW TO USE
Done!
Model-3
Put the switch lever in the
center position.
1
Pump about 30 times.
2
The upper handle controls
the upper linkage.
3
The lower handle controls
the lower linkage.
5
The gripper will open when
the switch lever is up.
7
The gripper will close when
the switch lever is down.
9
8
10
4
6
24
Connection
300-mm tube
1 2 3
450-mm tube
Connection
450-mm tube
Connection
48 49
50
51
