What’s inside your experiment kit:

Checklist: Find – Inspect – Check oﬀ

No. Description Qty. Item No.

1 Axle, 10 cm 2 703 234

2 Axle, 15 cm, without head 1 703 518

3 Axle, 4 cm, without head 1 715 807

4 Axle, 6 cm 2 703 238

5 Axle, 7 cm 1 723 892

6 Worm screw 1 715 046

7 Axle lock 3 702 813

8 Red anchor pin 30 702 527

9 Joint pin 4 702 524

10 Shaft plug 7 702 525

11 Hinge 10 715 052

12 Rubber band, medium 2 703 241

13 Rubber band, XL 1 715 801

14 Hook 1 706 533

15 5-hole dual rod 2 715 675

16 Long dual rod 4 715 676

17 90-degree converter - X 5 715 051

18 Crank 1 719 237

19 Dual frame 2 715 045

20 Long frame 3 727 602

21 Square frame 6 714 284

22 Short frame 3 715 044

23 Wheel 4 715 049

No. Description Qty. Item No.

24 Medium pulley wheel 1 707 010

25 Two-to-one converter 4 714 286

26 11-hole rod 3 714 282

27 3-hole rod 5 715 042

28 5-hole rod 3 714 179

29 Curved rod 2 714 285

30 Washer 6 727 601

31 Large gear wheel, yellow 1 715 047

32 Small gear wheel, red 5 710 062

33 Medium gear wheel, blue 2 716 179

34 Extra-large gear wheel, orange 1 715 048

35 Small body plate 2 715 280

36 Body plate 3 1 714 276

37 Body plate 4 1 714 277

38 Blue anchor pin 2 717 767

Anchor pin lever

(Part separator tool)

1 702 590

40 Horn 1 715 054

41 Elastic cord 1 703 245

42 String 1 714 240

43 Spiral spring 1 714 475

44 Wooden ball 1 703 243

45 Die-cut sheets (3) 1 729 799

12 13

38 39 40 41 42 43 44

33 34 35 36 37

22 23 24

25 26 27 28 29 30

14 15 16 17 18 19 20

2 3 4 5 6 7 8 9 10 11

› › › KIT CONTENTS
