TABLE OF CONTENTS

Code+Control Dinosaur Robot: REX

Kit Contents ................................... Inside front cover

Table of Contents ......................................................... 1

Safety Information ....................................................... 2

Important Information ................................................. 3

Adventure Comic Part 1 ............................................... 4

ASSEMBLY INSTRUCTIONS BEGIN ON PAGE 9

REX Assembly ................................................. 8

Remote Control Assembly ................................ 25

Adventure Comic Part 2 .................................. 26

Sticker placement ........................................... 28

Using the Remote Control & Programming REX 29

Check It Out! ................................................. 31

No. Description Quantity Part No.

D1 Left arm 1 726745

D2 Claw, left arm 1 726743

D3 Armor, left arm 1 726743

E1 Tail tip 1 726745

E2 Armor for tail tip, right 1 726743

E3 Armor for tail tip, left 1 726743

F1 Tail center 1 726745

F2 Armor for tail center, right 1 726743

F3 Armor for tail center, left 1 726743

G1 Body, right 1 726754

G2 Body armor, right 1 726766

G3 Body adornment, right 1 726772

H1 Body, left 1 726755

H2 Body armor, left 1 726767

H3 Body adornment, left 1 726773

I1 Body, center 1 726751

I2 Axis 1 726784

I4 Right body connector, gray 1 726768

I5 Left body connector, white 1 726771

I6 Left body connector, gray 1 726769

I7 Right body connector, white 1 726770

I8 Large lever 1 726744

I9 Connector 1 726744

I10 Cervical vertebra 1 726746

J2 Right eye support 1 726746

J3 Right eye 1 726746

J4 Head, right 1 726761

No. Description Quantity Part No.

J5 Head armor, right 1 726743

K2 Left eye support 1 726746

K3 Left eye 1 726746

K4 Head, left 1 726762

K5 Head armor, left 1 726743

L1 Infrared sensor 1 726776

L2 Sensor housing, front 1 726744

L3 Sensor housing, rear 1 726744

LED

Cable with LED 2 726777

M Jaw 1 726763

N Ribs 5 726746

O1 Battery box bottom, REX 1 726756

O2 Speaker 1 726782

O3 Circuit board, REX 1 726783

O4 Control box cover, REX 1 726758

O5 Battery box cover, REX 1 726759

P1 Circuit board, remote 1 726779

P2 Rubber buttons, remote 1 726778

P3 Remote control front 1 726749

P4 Remote control back with

battery cover 1 726748

ST Sticker sheet 1 726742

T1 Long screw 10 726785

T2 Short screw 8 726786

Z1 Right motor 1 726780

Z2 Left motor 1 726781

You will also need:

Diagonal cutters or scissors and nail file, Phillips-head screwdriver

(PH1 size recommended), 6 AA batteries (1.5-volt, type LR6).





ADDITIONAL

information

can be found in the

CHECK IT OUT

sections on pages

and

32.

620397-02-051222
