13
Start: Illustration G+I
Never start the mower directly on long grass.
1. Open the batttery cover (9) on the motor unit, slide
in the batteries (10) and click them both in place.
2. Make sure the safety key (12) is inserted.
3. Hold the start button (1) down and activate the
handlebar for engine brake (2) to start the motor.
Release startbutton once started.
Note: As long as operating the mower, the handlebar
for engine brake must be engaged.
Important! Use with both batteries at the same time.
In order to cut with full power, the lawn mower must be
used with both batteries installed.
Make sure both batteries are fully charged before use.
The lawn mower cannot be used, if one battery is
removed or it is almost drained for power.
Stop:
1. Release the engine brake to turn off the mower and
the engine
Note: The blades will still rotate at up to 3 seconds
after stopping.
Remove the battery
To remove the battery, press and hold the latch button
under the battery and pull it out.
Working time
The working time per full charge depends of several
factors, like length of grass, cutting height and cutting
methods (mulching or collection).
Variable motor-speed
The motor adjusts the blade-rotations to match the load
(length and thickness of the grass). You will therefore
hear that the motor-speed will go up/down while cutting
the grass. This is perfectly normal and ensures a more
energy-effective use of the power from the battery.
Indicator for full grass collector: Illustration K
The practival indicator (23) on the grass collectors tells,
when it is full of grass and need to be emptied.
Blade
Inspection of the blade
• Tilt the mower with the front upwards.
• Inspect blade for damage, cracks or excessive rust
or corrosion.
• Check that the blade bolt is tightened.
Note: A dull blade can be sharpened! But a blade that
is worn, bent, cracked or otherwise damaged must be
replaced.
Removing the blade: See illustration H
If you remove the blade to sharpen or replace it, you
must use a torque wrench and some heavy gloves to
protect your hands.
1. Loosen the blade bolt (21) with a suitable tool. Use
a piece of wood to prevent the blade from turning
around.
2. Remove the bolt and blade from blade holder (22)
3. Sharpen or replace the blade.
4. Mount blade and bolt.
5. Tighten the blade bolt with 25 Nm with a suitable
tool. Use a piece of wood to prevent the blade from
turning around.
Warning: A blade must be sharpened so it is in
100 % balance, otherwise it may cause vibrations that
could damage the engine. Damage to engine due to
faulty sharpening is not covered by warranty. We
therefore recommend letting a service center sharpen
the blade.
Storage and maintenance
Maintain your lawnmower: Check all bolts, screws,
nuts and deck. Dismount the blade and the belt plastic
cover for regular cleaning. Always make sure that the
blade is sharp. Keep the motor unit free from grass and
dirt. It’s a good idea to take your lawn mower to an
annual service check with your authorized service
dealer. See your nearest service center at
www.texas.dk.
Storage: After use the lawnmower kept in a dry and
clean room. Clean the machine after every use. Grass
and dirt must be removed from the underside of the
deck. Remove the safety key before cleaning and
storage.
Winter storage: Spray silicone lubrication into the
cables and move them.
Finally, clean the mower thoroughly. Dip a cloth in oil
and luricate metal parts to prevent rust. For storage of
battery, see “Battery” section.
Specifications
Lawn mower model
Razor 4300Li
Motor
2 x 18V battery
Self-propelled
No
Cutting width
43 cm
Height adjustment
25-75 mm (6 positions)
Mulching
Yes
Side discharge
No
Grass collector
50 L
Weight
13.8 kg incl. batteries
Vibrationlevel
0.37 m/s
2
(K=1.5 m/s
2
)
Soundp pressure L
pA
72.8 dB(A) (K=3 dB)
Sound power L
wA
87.1 dB(A) (K=2.95 dB)
Gauaranteed L
wA
96 dB(A)
Batteri
Type
18V Lithium-Ion
Capacity
4.0 Ah (75 Wh)
Full charging time
100 min
Cutting capacity/charge
Up to 600 m
2
