17
This is ensured by always keeping the same steady RPM on
the trimmer head. Avoid downspin in RPM. A downspin in
the RPM on trimmer head can be a sign on overload.
Adjustment of the cutting height and handlebar
Cutting height
Follow the adjustment procedure as shown in Fig. 10
It is possible to adjust the cutting height on the trimmer head
in several positions between 45-120 mm.
Adjusting the cutting height is done by unscrewing the
bottom of the trimmer head (counterclockwise) and moving
the plastic discs around. If the cutting height is to be
increased, move the discs under the line holder. See
examples A and B. Tighten the bottom part again by
tightening it clockwise.
Handlebar
See Fig. 11+12
The angle of the handlebar can be adjusted up, down and
sideways. Use the handle rod and handwheel on the
handlebar console. Be careful not to pinch cables.
Cleaning
The machine should be cleaned after use. Use a garden
hose to wash off soil and dirt. Remove the trimmer head from
the trimmer axel to remove wedged grass etc. from the rotor
shaft. The chassis number should only be cleaned with a
damp cloth to avoid unnecessary wear. Avoid using a high-
pressure washer during cleaning.
Changing the oil
The oil should initially be changed after the first 5 hours of
use, and thereafter once per year. Use an oil extractor kit.
1. Suck the oil up through the oil filler hole using the
syringe. Use the hose to reach the sump.
2. Transfer the used oil to the container.
3. Fill the engine with new SAE-30 oil.
4. Check the oil level using the dipstick.
Remember to dispose of used oil in a safe way.
Oil and oil extractor kit are not included
Storage
If the machine is likely to be stored unused for prolonged
periods, follow the instructions below. This will ensure
longer machine lifetime.
Use a garden hose to wash off soil, grass and dirt.
Remove any grass, etc. from the shaft. The chassis
number should only be cleaned with a damp cloth to
avoid unnecessary wear. Avoid using a high-pressure
washer during cleaning.
Wipe the machine with a damp cloth so that all surfaces
are clean. Wipe the surfaces down with an oily cloth to
prevent rust.
Always store the machine in a dry, clean location.
Troubleshooting
The motor will not start
1. Check the spark plug.
2. Check there is fresh gas in the tank.
3. See separate motor instructions for further
troubleshooting.
The motor is not running smoothly
1. Check there is fresh gas in the tank.
The trimmer will not rotate
1. Check the cables are in good working order and fitted
correctly.
2. Check and remove wedged grass.
3. Check that the belt is fitted correctly.
Noise, vibration and precautionary measures
1. Long-term exposure to noise levels exceeding 85 dB (A)
are damaging. Always use ear defenders when the
machine is being used.
2. To reduce noise levels further, only use the machine in
an open environment.
3. Vibrations can be reduced further by holding the handle
firmly.
4. To avoid disturbing others, the machine should only be
used during the daytime.
5. Always wear close-fitting work clothes, hard-wearing
work gloves, ear defenders and non-slip boots with steel
toecaps.
6. Take a 30-minute break every 2 working hours.
Specification
Engine TG595 173cc (Rato RV170)
Effect 2,9 KW/3000 Rpm.
Working width Max 60 cm
Working Hight 45-120 mm
Trimmer line 4 mm
Transmission Push
Wheels 14”
LpA 84.2 dB(A)
LwA 104 dB(A)
Vibrations (L / R) 6,7 m/s
2
/ 5,0 m/s
2
Weight 50.5 kgs
