19
12. Rewinding the spool
Before any service and maintenance is done, the power must be disconnected,
it means the battery removed from the tool.
The spool is supplied with the nylon line on it.
When need to rewind the spool with new nylon line, follow these steps:
1. Press the two plastic parts to remove the bottom cover.
2. Cut a piece of nylon line (1.6 mm) of maximum 12 meter.
(you may find it easier to practice with a shorter line length first)
3. Find the center of the line and loop it onto the notch on the spool (Fig. 1)
4. Wind the line around the spool in the direction indicated by the arrows. Keep each end
of the line in its own channel (no crossing). Keep the line tight as you wind, so that the
line is fitted nicely without crossing (Fig. 2).
Wrong winding can result in the trimmer head not working properly.
5. Wind the line until about 20 cm left in both sides.
6. Keep the line tight and fix both ends to the notches in the spool (Fig. 3).
7. Put the spool back in place and put the line ends through the holes in each side.
Pull both line ends when the spool is in place (Fig. 4).
8. Remount the bottom cover.
Fig. 1
Fig. 2
Fig. 3
Fig. 4
