Je bekijkt pagina 77 van 81

Ranger Micro System

TRANSMITTER RECEIVER

VIDEO

Video Inputs

3G-SDI SMPTE 2082 standard / 75 Ω

(BNC x 1)

1 x HDMI 1.4b Type-A receptacle

N/A

Video Outputs

3G-SDI SMPTE 2082 standard / 75 Ω

(BNC x 1)

3G-SDI SMPTE 2082 standard / 75 Ω

(BNC x 2)

1 x HDMI 1.4b Type-A receptacle

Color Sampling

SDI: YCbCr 4:2:2, 10-bit

HDMI: RGB / YCbCr 4:4:4, 8-bit | YCbCr

4:2:2 10-bit

SDI: YCbCr 4:2:2, 10-bit

HDMI: RGB / YCbCr 4:4:4, 8-bit | YCbCr

4:2:2 10-bit

Delay (TX to RX)

<0.001sec (without format

conversions)

<0.001sec (without format

conversions)

Supported

Resolutions

1080p23.98/24/25/29.97/30/50/59.94/60

1080psf23.98/24/25/29.97/30

1080i50/59.94/60

720p50/59.94/60

576i/480i

480p50 576p59.94 (HDMI only)

Input Cross

Conversion

Yes, HDMI to SDI N/A

Output Video

Scaling

N/A Yes, Auto scaling to 1080p

VIDEO PROCESSING

Video

Compression

Uncompressed Uncompressed

Test Pattern

Generator

N/A Yes

Video Format

Conversion

Yes Yes

Teradek User Manual
