Teradek products are built to comply with regulatory requirements for all markets in which they are sold.
As such, we can only enable U-NII-5 support in the regions where it is approved for license-free use.
Teradek will release `rmware updates with additional regional support as they become available.
+8:<A@ .'""BBDAH4> <D?I4D84H4<>45>8 JB86F874H4<>45<><FK
US (FCC) Yes Yes Now
Europe In Process No 2023
Canada Yes Yes Now
Japan (Indoors) In Process No 2023
Japan (Outdoors) In Process No 2023
South Korea In Process No 2023
Australia/New Zealand TBD No 2023
NOTE: additional region support TBD, will be added as regulation and certi`cation allows
A@R:GD4F<A@
By default, Ranger Mk I operates in the 5GHz range. This allows backwards compatibility with Ranger
Mk II and Micro systems and in low interference environments will allow for the highest maximum
range. Switching to U-NII-5 (6GHz) frequencies allows Ranger Mk II and Micro to operate with minimal
interference as very few other products support these frequencies. To con`gure Ranger Mk II and Micro
for 6GHz operation simply switch TX and RX units to the 6GHz band in the wireless settings menu. This
can be done via the app or OLED display.
• -1: open menu, Wireless Settings, frequency range. Select 6GHz
• +1: open menu, Wireless Settings, frequency range. Select 6GHz
Associated menus for frequency selection will only show frequencies for the selected bands. Automatic
frequency hopping works on either the 6GHz or 5GHz bands, but does not support scanning both. All
systems must be set to 6GHz to work in the 6GHz range.
