>>AI%<68@E87;4@@8>E

Enable or disable Licensed Channel selection within the Frequencies menu. Ranger supports an

extended RF range of 4.9GHz to 6.0GHz, which includes both unlicensed and licensed channels.

Selecting a speci`c licensed channel ensures there is no interference from other devices broadcasting

within range. This is especially useful during large events such as sports or news broadcasts where

multiple cameras are operating simultaneously. For all available frequencies, refer to the +*.'",

2+ "('chart.

'(-<J87D8CG8@6K&A78?GEFRDEF588@45>87FAE8>86F4EB86<R6><68@E876;4@@8>(F;8DI<E8

+4@:8DI<>>4GFA?4F<64>>KE8>86F4><68@E876;4@@8>GFA&A78

,8>86F4@7I<7F;

The Bandwidth menu lets you choose between 40MHz (default) and 20MHz operating modes. Ensure

that both the transmitter and receiver are set to the same bandwidth with a resolution of up to 1080p60.

For all available frequencies, refer to the+*.'",2+ "('chart.

• &!L- Reduces the amount of bandwidth by half, effectively doubling the number of usable

frequencies while decreasing interference.

• &!L - (Default) Increases the amount of bandwidth by bonding two 20MHz frequencies, allowing

for faster transfer rates but increased interference.

'(-&!L?A78EGBBADFE! D8EA>GF<A@EGBFAB+8EA>GF<A@EGBFA=4D84>EA

EGBBADF875GF7AI@E64>87FAB589AD8FD4@E?<EE<A@=<E@AFEGBBADF87

,8>86FD8CG8@6K

The Frequencies menu contains a list of all available frequencies. Ranger will automatically select an

operating frequency when multiple values are selected. If both the transmitter and receiver have <J87

D8CG8@6K&A78 enabled, you can only select one frequency for Ranger to use. Frequencies marked

with (DFS) must be scanned for one minute before they can be used, but are typically less crowded. For

all available frequencies, refer to the +*.'",2+ "('chart.

/<78A*G4><FK-1A@>K

The Video Quality menu lets you adjust the balance between your signal’s maximum range and quality

according to the number of antennas used to transmit `ne information. Ranger has three picture quality

levels that vary based on the lowest quality link or the furthest receiver.

• GFA&A78- (Default) Transmitter automatically determines how many `ne antennas are needed

based on the range and signal quality.

• %A@:8D<EF4@68&A78 - Maintains the maximum range in situations where other sources of

interference might be present, but will slightly reduce your video signal’s maximum quality.

Teradek User Manual

)4:8Ranger Micro | Mk II
