)4<D<@:.@B4<D<@:

Ranger devices purchased as a set (TX and RX), are paired by default, requiring no additional

con`guration. Ranger devices purchased separately need to be paired using the device's front panel

(OLED) menu, %4G@6;B47, or +4@:8D&4@4:8D. To pair your transmitter with multiple receivers, you will

need to use either Launchpad or +4@:8D&4@4:8D. '(-89AD8EF4DF<@:8<F;8DB4<D<@:BDA68EE8@EGD8

F;4F5AF;F;8FD4@E?<FF8D4@7D868<H8D;4H8F;8E4?8RD?I4D8H8DE<A@4@7;4H8>G8FAAF;8@45>87

)"+"' .')"+"' /"+('-)'%

-A)4<D

1. Using the Menu Joystick, navigate to the )4<D menu on both the transmitter and the receiver front

panel.

2. Select )4<D to begin the pairing process. The transmitter will begin scanning for a receiver within

range and automatically pair with the receiver.

3. Once paired, the front panel will indicate whether or not Pairing is successful.

-A.@B4<D

1. Navigate to the .@B4<D menu on either the transmitter or the receiver.

2. Select the transmitter/receiver you want to unpair. If you have multiple devices paired, you can select

.@B4<D>>.



)"+"' -"),

If you’re having trouble getting units to pair, we recommend keeping the transmitter and

receiver six feet apart when pairing. Keep all other RF devices nearby turned off or out of range

to ensure the transmitter and receiver only detect each other. To eliminate any chance of

interference, perform the Wired Pairing process via Launchpad.

0"+)"+"' /"%.'!)

-A)4<D

1. Connect both the transmitter and receiver(s) to your computer (Windows/Mac) via USB.

2. Open Launchpad, select the )4<D<@:tab, then tap the 0<D87)4<D<@:button.

3. Select the devices you want to pair, then click the )4<D8H<68Ebutton. Launchpad will indicate

whether or not Pairing is successful.

-A.@B4<D

1. Connect both the transmitter and receiver(s) to your computer (Windows/Mac) via USB.

2. Open Launchpad, select the )4<D<@:tab, then tap the .@B4<D>> button.

Teradek User Manual

)4:8Ranger Micro | Mk II
