106 107

Declaration - Electromagnetic Emission

Emissions test Compliance

RF emissions

CISPR 11

Group 1

RF emissions

CISPR 11

Class B

Harmonic emissions IEC

61000-3-2

Class A

Voltageuctuations/icker

emission

IEC 61000-3-3

Clause 5

Declaration - Electromagnetic Immunity

Immunity test IEC60601testlevel Compliancelevel

Electrostatic

discharge (ESD)

IEC 61000-4-2

±8 kV contact

±2 kV, ±4 kV, ±8 kV,

±15 kV air

±8 kV contact

±2 kV, ±4 kV, ±8 kV, ±15

kV air

Electrical fast

transient/burst

IEC 61000-4-4

± 2 kV for power

supply lines

± 1 kV for input/

output lines

± 2 kV for power supply

lines

± 1 kV for input/output

lines

Surge

IEC 61000-4-5

± 0.5kV, ± 1 kV

line(s) to lines

± 0.5kV, ± 1 kV, ± 2

kV line(s) to earth

± 0.5kV, ± 1 kV line(s) to

lines

± 0.5kV, ± 1 kV, ± 2 kV

line(s) to earth

Voltage

dips, short

interruptions

andvoltage

variationson

power supply

input lines

IEC 61000-4-11

0%UT;0.5cycle

At 0°, 45°, 90°, 135°,

180°, 225°, 270°and

315°

0%UT;1cycle

and=70%UT;25/30

cycles

Single phase: at 0°

0%UT;250/300

cycles

0%UT;0.5cycleAt0°,

45°, 90°, 135°, 180°, 225°,

270°and 315°

0%UT;1cycleand70%

UT;25/30cycles

Single phase: at 0°

0%UT;250/300cycles

Power frequency

(50/60 Hz)

magneticeld

IEC 61000-4-8

30 A/m 30 A/m

NOTE:UTisthea.c.mainsvoltagepriortoapplicationofthetest

level.

Declaration - Electromagnetic Immunity

Immunity test IEC60601testlevel Compliancelevel

Conducted RF

IEC 61000-4-6

3 V

0.15 MHz to 80 MHz

6 V in ISM bands

between 0.15 MHz

and 80 MHz

3 V

0.15 MHz to 80 MHz

6 V in ISM bands between

0.15 MHz and 80 MHz

Radiated RF

IEC 61000-4-3

10V/m

80 MHz to 2.7 GHz

10V/m

Declaration - IMMUNITY to proximity elds from RF wireless

communications equipment

Immunity

test

IEC60601 test level Comp-

liance

level

Test

frequency

Modu-

lation

Maximum

power

Immu-

nity

level

Radiated

RF

IEC

61000-

4-3

385 MHz **Pulse

Modulation:

18Hz

1.8W 27 V/m 27 V/m

450 MHz *FM+ 5Hz

deviation:

1kHz sine

2 W 28 V/m 28 V/m

710 MHz

745 MHz

780 MHz

**Pulse

Modulation:

217Hz

0.2 W 9 V/m 9 V/m

810 MHz

870 MHz

930 MHz

**Pulse

Modulation:

18Hz

2 W 28 V/m 28 V/m

1720 MHz

1845 MHz

1970 MHz

**Pulse

Modulation:

217Hz

2 W 28 V/m 28 V/m

2450 MHz **Pulse

Modulation:

217Hz

2 W 28 V/m 28 V/m

5240 MHz

5500 MHz

5785 MHz

**Pulse

Modulation:

217Hz

0.2 W 9 V/m 9 V/m

Note*-AsanalternativetoFMmodulation,50%pulsemodulation

at 18 Hz may be used because while it does not represent actual

modulation, it would be worst case.

Note** - The carrier shall be modulated using a 50 % duty cycle square

wavesignal.
