68
6.7 QVLAN Settings
6.7.1 Overview
The AP supports 802.1Q VLANs and is applicable in a network environment where 802.1Q VLANs
have been defined. By default, the QVLAN function is disabled.
If the QVLAN function is enabled, tagged data received by a port of the AP is forwarded to the other
ports of the VLAN corresponding to the VID in the data, whereas untagged data received by a port
of the AP is forwarded to the other ports of the VLAN corresponding to the PVID of the port that
receives the data.
The following table describes how ports of different link types process transmitted and received
data.
Port
Method to Process Received Data
Method to Process Transmitted
Data
Tagged Data
Untagged Data
Access
Forward the data to other
ports of the VLAN
corresponding to the VID in
the data.
Forward the data to the
other ports of the VLAN
corresponding to the PVID of
the port that receives the
data
Transmit data after removing tags
from the data.
Trunk
If the VID and PVID of a port are
the same, transmit data after
removing tags from the data.
If the VID and PVID of a port are
different, transmit data without
removing tags from the data.
