140
Document version: V1.0
8.11.1 Set up port mapping to a local server
To forward specific incoming protocols to a local server:
1. Decide which type of service, application, or game you want to provide.
2. Find the local IP address of the computer on your network that will provide the service.
The server computer must always use the same IP address. To specify this setting, use the
reserved IP address feature. See Manage reserved LAN IP addresses.
3. Launch a web browser from a computer that is connected to your NOVA network.
4. Enter tendawifi.com.
A login window displays.
5. Enter the login password.
The password is case-sensitive.
6. Go to More > Advanced > Port Mapping.
7. Click Add.
8. Specify the local server computer by one of following methods:
− Select a device from Select Device menu.
− Select Manual from Select Device menu, and then enter the IP address of the local server
in the Internal IP Address field.
9. Specify the Internal Port by one of following methods:
− Select a port number from Internal Port menu.
− Select Custom from Internal Port menu, and then enter the service port number of the
local server.
10. In the External Port filed, enter the port numbers.
11. In the Protocol menu, select the protocol.
If you are unsure, select TCP/UDP.
12. Click OK.
---End
Your settings are saved. The service is now in the table on the Port Mapping page.
8.11.2 Example: Make a local FTP server public
Scenario: You have set up an FTP server on the local network.
