〓〓〓〓〓〓 OSD MENU 〓〓〓〓〓〓
— 33
—
1. Under working mode, press the MENU key on the IR remote controller, to
enter the OSD menu as below:
2. After entering the main menu, use the navigate UP/DOWN key to select the
main menu. Once selected, the main menu will change to the blue background,
and the right side will show sub-menu options.
3. Press the navigate RIGHT key to enter the sub-menu; use the UP/DOWN key
to select the sub-menu; use the LEFT/RIGHT key to select the parameter.
4. Press the MENU key again to return to the previous menu. Press the MENU
key continuously to exit the OSD menu.
5. OSD Menu Setting List
SYSTEM
PROTOCOL
Optional: VISCA, PLC.P, PLC.D
Default: VISCA
ADDRESS
VISCA:: 1~7 PLC-P/D: 0~255
Default: 1
BAUDRATE
Optional：2400, 4800, 9600, 115200
Default: 9600
PROTOCOL
LOCK
Optional：OFF, ON
Default: OFF
RS485
Optional：OFF, ON
Default: ON
LANGUAGE
Optional: ZH-CH, ENGLISH, ZH-TW,
RUSSIAN
Default: ENGLISH
AT TRACKING
Optional：OFF, ON
Default: OFF
AT LOCATION
Optional：MIDDLE、LEFT、RIGHT
Default: MIDDLE
AT RATIO
Optional：1/6~1/20
Default: 1/16
